Implants For Short Eyes
Type 13S
| Size (open) | 10.5 mm |
|---|---|
| Size (compressed) | 9.0 mm |
| Zonular Damage | up to 4 hours (120°) |
| Material | CLEAR PMMA |
| Instruction For Use | eIFU-System |
Type 1S
| Size (open) | 10.66 mm |
|---|---|
| Size (compressed) | 8.5 mm |
| Zonular Damage | > 4 hours (120°) |
| ACCC* | 6.0 mm |
| Suturable Arms | one |
| Material | CLEAR PMMA |
| Fixation | We recommend the use of 9-0 double armed prolene sutures with spatula needles |
| Instruction For Use | eIFU-System |
| Note | Cannot be implanted with an injector! |
Type 89A
Indication | Adults/Pediatrics |
|---|---|
Total Diameter | 7.5 mm |
| Longest/smalest Diameter | 7.5/6.0 mm |
| Optic Diamter | 5.0 mm |
| Standard Diopter Range | 10.0 – 30.0 D (0.5 inc.) |
| On Request Diopter-Range | 8.5 – 9.5 D (0.5 inc.) 30.5 – 35.0 D (0.5 inc.) |
| Theoretical Standard Diopter | 23.0 D |
| Theoretical A-Con. (optical) | 118.2 |
| Theoretical ACD (optical) | 5.08 mm |
| Material | Hydrophilic Acrylic |
| Water Content | 28.0 % |
| Filter | UV-Filter |
| Refractive Index | 1.46 |
Recommended Caliper Ring*2 for ACCC*1 | |
| Note | Surgeons must partake in prerequiste course before implantation! |
| Security Advice | Due to the possibility of iris capture it is recommended to keep the pupil in myosis in the early postoperative period. |
| Media | Surgery Videos |
| Instruction For Use | eIFU-System |
Type 89D
Indication | For short eyes (< 18.0 mm) and/or |
|---|---|
Total Diameter | 6.5 mm |
| Longest/smalest Diameter | 6.5/5.25 mm |
| Optic Diamter | 4.5 mm |
| Standard Diopter Range | 10.0 – 30.0 D (0.5 inc.) |
| On Request Diopter Range | 8.5 – 9.5 D (0.5 inc.) 30.5 – 35.0 D (0.5 inc.) |
| Theoretical Standard Diopter | 23.0 D |
| Theoretical A-Con. (optical) | 118.2 |
| Theoretical ACD (optical) | 5.08 mm |
| Material | Hydrophilic Acrylic |
| Water Content | 28.0 % |
| Filter | UV-Filter |
| Refractive Index | 1.46 |
Recommended Caliper Ring*2 for ACCC*1 | |
| Note | Surgeons must partake in prerequiste course before implantation! |
| Security Advice | Due to the possibility of iris capture it is recommended to keep the pupil in myosis in the early postoperative period. |
| Media | Surgery Videos |
| Instruction For Use | eIFU-System |
